High End Track Roll Forming Machine Price List
Product details of the track roll forming machine
Product Specification
Type: Forming Machine
Cutting type: Hydraulic Cutting
Marketing Type: Ordinary Product
Condition: New
After-sales Service Provided: Service Machinery Overseas
Quick Detail
The design style of Liding Machinetrack roll forming machine expresses the details thoroughly. By enhancing the performance of track roll forming machine, the worries of our users can be reduced. With competitive price, our track roll forming machine has been more popular which also makes Liding Machine to be more competitive.
Product Introduction
Compared with similar products, our track roll forming machine has the following major characteristics.
Bottom reinforcement steel roll forming machine for elevators
Application
Other profiles
Specification
|
Serial number
|
composition
|
data
|
|
1
|
Manual Decoiler
|
Max. bearing load capacity 3000kg
|
|
2
|
Leveler
|
1 set
|
|
3
|
Sensor racks
|
2 set
|
|
4
|
Hydraulic punching unit
|
7 stations
|
|
5
|
Cold roll forming integral machine
|
1 set
|
|
6
|
Cutting device
|
1 Set
|
|
7
|
Hydraulic system
|
5.5KW
|
|
8
|
PLC automatic control equipment
|
Famous brand
|
Production process
Decoiling→ Roll Forming →Straightening → servo feeding → punching → roll forming → automatic cutting → unloading
|
Condition
|
New
|
|
Production Capacity
|
0-8m/min
|
|
Place of Origin
|
China,Guangdong
|
|
Brand Name
|
Liding
|
|
Voltage
|
380V 50Hz 3phases
|
|
Warranty
|
1 Year
|
|
Key Selling Points
|
High-accuracy
|
|
Machinery Test Report
|
Provided
|
|
Video outgoing-inspection
|
Provided
|
|
Warranty of core components
|
1 Year
|
|
Product name
|
Full Auto Omega Profile Channel roll forming machine
|
|
Roller material
|
cr12mov
|
|
Cutting blade material
|
CR12mov
|
|
Transmission
|
Gear
|
Main parameters
1 Main motor power 11KW
2 Transmission form Gear, chain
3 Rolling speed 0-8M/min
4 Maximum feeding width 250mm
5 Rolling mold material Cr12
6 Rolling mold heat treatment hardness HRC58-62
7 Mold surface roughness Ra0.8
8 Roller shaft material, diameter 40Cr, φ60
9 roller groups: 18+5
10 mold life ≥1.6 million meters
11 Residue recovery method Filter collection
12 Rolling mold replacement method Overall lifting, positioning pin fixed
Product display
Company Information
After years of self-development, 佛山市立鼎科技有限公司 has received a good reputation in the industry and by providing high-quality and innovative track roll forming machine. Liding Machine uses cutting-edge technology to enhance market position. 佛山市立鼎科技有限公司 aims to create a more brilliant future with more customers around the world together. Inquire!
We are committed to providing customers with quality products. We sincerely welcome customers with needs to contact us, and look forward to establishing a long-term friendly relation with you!
